Data Sheet

Cisco SFE1000P 8-Port 10/100 Ethernet Switch: PoE/Fanless

Cisco Small Business Managed Switches

Secure, Reliable, Managed Ethernet Switching with PoE

Highlights

●

Power over Ethernet easily and cost-effectively powers wireless access points, video cameras, and other

network-connected endpoints

●

Strong security protects network traffic to keep unauthorized users off the network

●

Intelligent QoS helps ensure a consistent network experience and supports networked applications including

voice, video, and data storage

●

Compact size and fanless design are ideal for areas with limited space

●

Limited lifetime warranty

Figure 1. Cisco SFE1000P 8-Port 10/100 Ethernet Switch: PoE/Fanless

Product Overview

The Cisco

SFE1000P 8-Port 10/100 Ethernet Switch (Figure 1) is an 8-port fully managed 10/100 Ethernet switch

with two Gigabit copper or optical interfaces for connecting to a core switch.

For wireless or voice over IP (VoIP) deployments, the Cisco SFE1000P supports the IEEE 802.3af standard for

Power over Ethernet (PoE). With automatic load sensing, the power control circuitry automatically detects PoE on

end devices before providing power. (PoE is limited to the fixed 10BASE-T/100BASE-TX ports.) The unit can provide

maximum output power of up to 15.4W per PoE port on four ports, or up to 7.5W per PoE port on eight ports

simultaneously. It provides independent overload and short-circuit protection for each port. LED indicators indicate

the power status for each PoE port.

With the enhanced quality of service (QoS) and traffic-management features provided by the Cisco SFE1000P, voice

and video data can be prioritized, ensuring clear and reliable voice communications. An intuitive, secure

management interface enables you to easily set up the QoS parameters, along with the other advanced security and

performance features, resulting in an optimized, more secure network.
