Data Sheet

© 2009 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 1 of 22

Cisco Catalyst 3750-E Series Switches

The Cisco

®

Catalyst

®

3750-E Series Switches with StackWise Plus (Figure 1) is an

enterprise-class line of stackable wiring closet switches that facilitates the deployment of

secure converged applications while maximizing investment protection for evolving

network and application requirements. Combining 10/100/1000 and Power over Ethernet

(PoE) configurations with 10 Gigabit Ethernet uplinks, the Cisco Catalyst 3750-E

enhances worker productivity by enabling applications such as IP telephony, wireless, and

video.

Cisco Catalyst 3750-E Series Primary Features

●

Cisco TwinGig converter module for migrating uplinks from Gigabit Ethernet to 10 Gigabit

Ethernet

●

Cisco EnergyWise for greenhouse gas emissions and operational cost optimization by

measuring, reporting, and reducing energy consumption across the entire corporate

infrastructure, well beyond the scope of IT

●

PoE configurations with up to 15.4 W of PoE on all 48 ports

●

Enhanced PoE supporting up to 20W of PoE per port

●

StackWise Plus for ease of use and resiliency with 64 Gbps of throughput

●

Modular power supply with externally available backup

●

Multicast routing, IPv6 routing, and access control list in hardware

●

Out-of-band Ethernet management port along with RS-232 console port

Figure 1. Cisco Catalyst 3750-E Series Switches (front and back)

Switch Configurations

Table 1 shows the Cisco Catalyst 3750-E Series configurations:

Table 1. Switch Configurations

Feature Description

Cisco Catalyst 3750E-24TD 24 Ethernet 10/100/1000 ports and 2 X2 10 Gigabit Ethernet uplinks

Cisco Catalyst 3750E-24PD 24 Ethernet 10/100/1000 ports with PoE and 2 X2 10 Gigabit Ethernet uplinks

Cisco Catalyst 3750E-48TD 48 Ethernet 10/100/1000 ports and 2 X2 10 Gigabit Ethernet uplinks

Cisco Catalyst 3750E-48PD 48 Ethernet 10/100/1000 ports with PoE and 2 X2 10 Gigabit Ethernet uplinks

Cisco Catalyst 3750E-48PD-F 48 Ethernet 10/100/1000 ports with > 15.4 watts PoE on all 48 ports and 2 X2 10

Gigabit Ethernet uplinks
