Release Notes for Cisco IOS Release 12.4T
OL-8012-09 Rev. B0
Platform-Specific Information
The supported WICs and VICs are:
• VIC2-2FXO
Table 1 Supported Interfaces on the Cisco IAD2430 Series Integrated Access Devices
Interface and Port Product Description Supported IAD2430 Models
10/100BASE-T Fast Ethernet port All Cisco IAD2430 series models have two
10/100BASE-T Fast Ethernet ports except for
Cisco2431-8FXS IAD, which has one.
All
Console and auxiliary ports One EIA/TIA-32 asynchronous serial port for
connection to a console.
One EIA/TIA-32 asynchronous serial port for
connection to a modem.
All
Console and auxiliary ports Dual purpose single EIA/TIA-32 asynchronous
serial port for connection to a console or modem.
IAD2435-8FXS
Analog FXS voice ports over RJ-21
connector
One 8-line or 16-line analog or 24-line FXS
interface (loop-start or ground-start) for
connection to analog phones, key systems, or
PBXs.
• IAD2430-24FXS: 24 ports
• IAD2431-8FXS: 8 ports
• IAD2431-16FXS: 16 ports
• IAD2432-24FXS: 24 ports
• IAD2435-8FXS
VIC2-4FX0 All models support one VIC slot, except for
Cisco IAD2430-24FXS IAD, which supports
none.
• IAD2431-8FXS
• IAD2431-16FXS
• IAD2431-1T1E1
• IAD2432-24FXS
T1/E1 Port Two or one T1 ports for WAN connection or with
channel-associated signaling (CAS) for
connection to a digital PBX, except for
Cisco IAD2430-24FXS IAD, which supports
none. E1 ports are not supported.
• IAD2431-8FXS: 1 port
• IAD2431-16FXS: 1 port
• IAD2431-1T1E1: 2 ports
• IAD2432-24FXS: 2 ports
WIC-2T All models support one WIC slot, except for
Cisco IAD2430-24FXS IAD, which supports
none. The supported WICs are WIC-2T and
WIC-1DSU-T1.
One 2T port (balanced, per ANSI T1.403) for
connection to a WAN or carrier network or for a
serial connection
• IAD2431-8FXS
• IAD2431-16FXS
• IAD2431-1T1E1
• IAD2432-24FXS
WIC-1DSU-T1 One DSU port for connection to a WAN or
carrier network.
• IAD2431-8FXS
• IAD2431-16FXS
• IAD2431-1T1E1
• IAD2432-24FXS
External compact flash card An external compact flash card is supported on
all models.
All
