Data Sheet

Upgrade kit available for Cisco

TelePresence 30x0 rooms

You can convert a Cisco TelePresence System 30x0 room to a Cisco TelePresence System 3210 room in any

room with Cisco TelePresence System 3210 dimensions (8 ft H x 31 ft W x 23 ft D [2.4 x 9.4 x 7.0m] for the 12-

person table and 8 ft H x 24 ft W x 23 ft D [2.4 x 7.3 x 7.0m] for the 8-person table) or move an existing Cisco

TelePresence System 30x0 to a larger room.

Upgrade kit available for Cisco

TelePresence 3200 rooms

You can convert a Cisco TelePresence System 3200 room to a Cisco TelePresence System 3210 room to take

advantage of the improved data display experience.

Table 2 lists the overall features and benefits of the Cisco TelePresence portfolio.

Table 2. Cisco TelePresence Portfolio Features and Benefits

Feature Description

Any-to-any interoperability

support

Cisco TelePresence systems can interoperate with standards-based H.323 video conferencing systems and other

high-definition endpoints. In addition to protecting existing investments, interoperability dramatically expands the

number of video conferencing endpoints that can communicate with a Cisco TelePresence system.

Audio codec support G.711 and advanced audio coding with low delay (AAC-LD) audio compression codecs are available.

Cisco TelePresence Auto

Collaborate

This Cisco innovation allows people in all rooms to instantly see and share information or objects with others by

simply plugging in a device such as a laptop computer or the integrated optional high-definition document camera.

An optional presentation codec is dedicated to the data channel to provide full-motion (30-fps) graphics and

multimedia content on the Cisco TelePresence Auto-Collaborate data channel.

Cisco TelePresence Event

Controls

Through a web interface, event managers can control the flow of an event produced with a Cisco TelePresence

system—providing a cost-effective way to reach wide audiences with spectacular and compelling results.

Cisco TelePresence Expert on

Demand support

You can integrate Cisco TelePresence systems with Cisco® Unified Communications and Cisco Unified Contact

Center to deliver high-touch customer service and point-of-sale services.

Cisco TelePresence Extended

Reach

An optimized 720p Cisco TelePresence mode provides wide-area bandwidth connections as low as 1.5-Mbps

(T1/E1) speeds. The system maintains latency and packet loss while providing constrained bandwidth options

for remote-office or telecommuter deployments.

Cisco TelePresence Recording

Studio

Cisco TelePresence Recording Studio transforms Cisco TelePresence units into high-definition recording studios.

Using an intuitive user interface on your existing Cisco TelePresence IP Phone, you can record high-quality video to

deliver rich, immersive messages for internal and external communications, training, crisis management, etc.

Viewing and distributing video content is easy; you can replay recordings on Cisco TelePresence endpoints or on

standard browser-based players.

Cisco TelePresence WebEx

Engage

Cisco TelePresence WebEx Engage extends Cisco TelePresence meetings to Cisco WebEx users. This solution

offers unified scheduling and “one-button-to-push” meeting start, and it combines audio- and data-sharing

capabilities. Remote attendees join through the Cisco WebEx Meeting Center and receive video from the Cisco

TelePresence system. This integration improves user experience, making meetings easier and more productive.

Configuration options You can statically configure IP address assignment or configure it through the Cisco TelePresence administrator

web interface.

Dialing buttons These buttons allow for convenient manual or address-book dialing.

Directories Integration into the Cisco Unified Communications Manager general directory service provides a search function for

thousands of directory entries.

Document camera controls Software controls for the optional document camera have been incorporated into the Cisco TelePresence user

interface on the Cisco IP Phone, providing for a more tightly integrated solution and more natural user controls.

Encryption The Cisco TelePresence system supports full media and signaling encryption with no discernable latency to the

Cisco TelePresence call for up to 48 segments. In addition, Cisco TelePresence meetings can be designated as

nonsecure, secure best effort, and always secure. Meeting encryption status is indicated on-screen at the start of a

call or when it changes, and on the phone at all times.

Gigabit Ethernet switch The internal Cisco Gigabit Ethernet switch allows for a direct connection to a 10/100/1000BASE-T Ethernet network

through an RJ-45 interface with single LAN connectivity for both the Cisco TelePresence system and a co-located

Cisco Unified IP Phone 7975G and Ethernet-attached PC. The system administrator can designate separate

VLANs (802.1Q) for the PC and Cisco IP Phones, providing improved security and reliability of voice and data

traffic.

Multipoint support Cisco TelePresence systems can participate in multipoint meetings by using the Cisco TelePresence Multipoint

Switch.

Mute and hold The Cisco TelePresence system supports mute and hold functions.

The mute feature has an on-screen mute indicator to alert participants that the mute feature was activated on the

Cisco TelePresence microphone, causing all microphones to be simultaneously muted in remote rooms.

The Hold/Resume button toggles the video and audio mute features and allows you to place Cisco TelePresence

systems on hold for privacy.

Network-adaptive bandwidth

usage

The solution supports 720p or 1080p resolutions with three quality levels to optimize network bandwidth

consumption. The Cisco TelePresence system can operate at several different bandwidth levels ranging from 2 to 5

Mbps for configurable, variable bandwidth consumption, maximizing the Cisco TelePresence experience while

preserving frame rate and low latency and reducing packet loss. The solution is supported by all existing install,

deployment, and operation services.
